Splitter Panel 8 port MUX

[Photo of Eight to One Splitter Panel]

Provides a practical and robust method of daisy chaining SS7 links to up to seven acceSS7 Cardcages. The Splitter - Multiplexing Panel takes the input bearers and presents them on the eight output connectors for onward connection. The last connector should have a terminating plug fitted, 120 ohm for the High Speed Interface Card, or 130 ohm for the Low Speed Interface Card. Connectors are shielded female 50 way Amp Champ Telco. Cables are available for connection to acceSS7 Cardcages or additional Splitter Panels.

The Splitter is transparent to all data protocols and software.

These panels are suitable for installations where the network access points will be daisy-chained to more than one acceSS7 Cardcage. In similar circumstances with fewer circuits the Single Port Splitter Module is recommended.

Part NoDescription
TK-USP16-008-MUXSplitter Panel 8 Port MUX
TK-UTM16-130-AOOTerminator Unit 130 ohm Low Speed
TK-UTM16-120-AOOTerminator Unit 120 ohm High Speed
